Gipsskiva mot kraftig plåtregel, Weatherex II

Klicka på bilden för att zooma

Beskrivning

Gipsskiva mot kraftig plåtregel, Weatherex II

Visa mer Visa mindre

Harmoniserad standard EN 14566:2008+A1:2009

Har du frågor?

Produktinformation

Identifiering

Artikelnummer: 35Q30MW
GTIN: 8718035000620

Teknisk specifikation

Bandning: Plastbandad
Trådmaterial: Kolstål standard tensile
Varvtal: 2300, 2500, 3000, 3300 RPM

Infästning specifikation

Ytbehandling: Weatherex II
Applikationsmiljö: Fullt exponerad
Spets: Självborrande
Vinkel spets: 110 °
Skalle: Trumpetskalle
Spårtyp/bits: Philips 2
Gängning: Fingängad
Antal per strip/rulle: 50 - 50
Skruvlängd: 30.0 mm
Skruvdiameter: 3.5 mm

CE specifikation

DOP No: 35Q30MW
Materialinformation på CE-etiketten: Olegerat stål
Serviceklass: 3
Innergängans diameter: 2.65 mm
Längd gängning: 23.2 mm
Harmoniserad standard: EN 14566:2008+A1:2009

Övrig information

Förpackningsstorlek: 1000

Logistiska specifikationer

Nettovikt: 2.1 kg

Relaterade verktyg

Dokument

35Q30MW_sv_CommercialProductSheet_1.6_1750104019669 PDF 1 Mb
DOP DSP980005 PDF 403 Kb
DOP DSP980005 PDF 403 Kb
35Q30MW_sv_DeclarationOfPerformanceDoP_1.1eu_1750104110019 PDF 59 Kb
