Stål mot stålskruv PH2 elförzinkad 4,8x19mm

Klicka på bilden för att zooma

Beskrivning

Stål mot plåtregel, blank

Visa mer Visa mindre

Harmoniserad standard EN 14566:2008+A1:2009

Har du frågor?

Produktinformation

Identifiering

Artikelnummer: 48IP19MC
GTIN: 8715274028149

Teknisk specifikation

Bandning: Plastbandad
Trådmaterial: Kolstål standard tensile
Varvtal: 2300, 2500, 3000, 3300 RPM

Infästning specifikation

Ytbehandling: Elförzinkad
Applikationsmiljö: Skyddad miljö
Spets: Typ 17 spets
Vinkel spets: 110 °
Skalle: Flat
Spårtyp/bits: Philips 2
Gängning: Tek gängad
Antal per strip/rulle: 50 - 50
Skruvlängd: 19.0 mm
Skruvdiameter: 4.8 mm

CE specifikation

DOP No: 48IP19MC
Serviceklass: 1
Innergängans diameter: 3.8 mm
Längd gängning: 13.9 mm
Harmoniserad standard: EN 14566:2008+A1:2009

Övrig information

Förpackningsstorlek: 1000

Logistiska specifikationer

Nettovikt: 2.4 kg

Relaterade verktyg

Dokument

48IP19MC_sv_CommercialProductSheet_1.5_1752233836417 PDF 1 Mb
48IP19MC_sv_DeclarationOfPerformanceDoP_1.1eu_1750109958273 PDF 58 Kb
